Removal and Installation
8-112
HP DesignJet 5000 and 5500 Series Printers Service Manual
Center Guide Assembly
Removal
WARNING Switch off the Printer and remove the Power Cord.
NOTE Refer to the table on Page 8-4 for information on screw types.
1. Remove the Top Cover - Refer to
Page 8-5.
2. Remove the Back Cover - Refer to
Page 8-23.
3. Remove the Lower Right EMC Cover
- Refer to Page 8-32.
4. Remove Right Rear Cover - Refer to
Page 8-16.
5. Remove Left Rear Cover - Refer to
Page 8-15.
6. Remove the Deflectors - Refer to Page
8-119.
7. Remove the Left Hand Cover - Refer
to Page 8-6.
8. Remove the Right Hand Cover - Refer
to Page 8-10.
9. Remove the Left Hand Trim - Refer to
Page 8-22.
10. Remove the Right Hand Trim - Refer
to Page 8-20.
11. Remove the Media Lever Assembly -
Refer to Page 8-18.
12. Remove the ISS - Refer to Page 8-64.
13. Remove the Service Station - Refer to
Page 8-69.
14. Remove the Vacuum Fan - Refer to
Page 8-103.
15. Remove the Electronics Module -
Refer to Page 8-97.
