No Printing Defects Found in the Diagnostic Print
If all the test patterns from the Diagnostic Print are correct and you
still experience print quality problems, here are some of the more
likely causes to check:
The print mode used in the Printer is not right for the image that
is being printed (this is defined by the Printer’s Front Panel menu
selections).
Non-HP driver.
The RIP.
The software applications you are using.
Use the following table to configure your system correctly.
Print Quality Problems
For Color Accuracy and Consistency problems do the following:
Set the Color Calibration in Printer Setup/Internal RIP Settings/
Color Calibration to ON or turn it ON.
Perform a color calibration and print the plot again (any plots that
have already been processed by the Printer will not benefit from
the Calibration unless they are sent to the Printer again).
What to Configure Configuration Setting Optimal Setting
Printer Front-
Panel Menu
Media Set to match the media
type loaded in the
Printer
Dry time Set to Automatic.
HP driver
(Windows,
AutoCAD or
Mac)
Print mode setting Set to Max. Quality
Non-HP drivers
(Software RIPs)
The settings available
depend on the driver. The
most typical settings are:
Print Quality Settings
Half Tone
Media selection
See the user’s guide for
your application for more
information about its
print quality settings.
In the software
application:
Set Print Quality to Max.
Quality.
Use no Half Tone (or
Printer default).
Make sure that the
media setting matches
the media loaded in the
Printer.
