61
Table 32B — 5K Thermistor Temperature (C) vs Resistance/Voltage (cont)
VOLTAGE DROP A FOR THERMISTORS T1, T2, T7-T9
VOLTAGE DROP B FOR THERMISTORS T3-T6
TEMP
(C)
VOLTAGE
DROP A
(V)
VOLTAGE
DROP B
(V)
RESISTANCE
(Ohms)
–32
3.705 4.547 100,260
–31
3.687 4.520 94,165
–30
3.668 4.493 88,480
–29
3.649 4.464 83,170
–28
3.629 4.433 78,125
–27
3.608 4.402 73,580
–26
3.586 4.369 69,250
–25
3.563 4.335 65,205
–24
3.539 4.300 61,420
–23
3.514 4.264 57,875
–22
3.489 4.226 54,555
–21
3.462 4.187 51,450
–20
3.434 4.146 48,536
–19
3.406 4.104 45,807
–18
3.376 4.061 43,247
–17
3.345 4.017 40,845
–16
3.313 3.971 38,592
–15
3.281 3.924 38,476
–14
3.247 3.876 34,489
–13
3.212 3.827 32,621
–12
3.177 3.777 30,866
–11
3.140 3.725 29,216
–10
3.103 3.673 27,633
–9
3.065 3.619 26,202
–8
3.025 3.564 24,827
–7
2.985 3.509 23,532
–6
2.945 3.453 22,313
–5
2.903 3.396 21,163
–4
2.860 3.338 20,079
–3
2.817 3.279 19,058
–2
2.774 3.221 18,094
–1
2.730 3.161 17,184
0
2.685 3.101 16,325
1
2.639 3.041 15,515
2
2.593 2.980 14,749
3
2.547 2.919 14,026
4
2.500 2.858 13,342
5
2.454 2.797 12,696
6
2.407 2.737 12,085
7
2.360 2.675 11,506
8
2.312 2.615 10,959
9
2.265 2.554 10,441
10
2.217 2.494 9,949
11
2.170 2.434 9,485
12
2.123 2.375 9,044
13
2.076 2.316 8,627
14
2.029 2.258 8,231
TEMP
(C)
VOLTAGE
DROP A
(V)
VOLTAGE
DROP B
(V)
RESISTANCE
(Ohms)
15
1.982 2.200 7,855
16
1.935 2.143 7,499
17
1.889 2.087 7,161
18
1.844 2.031 6,840
19
1.799 1.976 6,536
20
1.754 1.923 6,246
21
1.710 1.870 5,971
22
1.666 1.817 5,710
23
1.623 1.766 5,461
24
1.580 1.716 5,225
25
1.538 1.667 5,000
26
1.497 1.619 4,786
27
1.457 1.571 4,583
28
1.417 1.525 4,389
29
1.378 1.480 4,204
30
1.340 1.436 4,028
31
1.302 1.393 3,861
32
1.265 1.351 3,701
33
1.229 1.310 3,549
34
1.194 1.270 3,404
35
1.160 1.231 3,266
36
1.126 1.193 3,134
37
1.093 1.156 3,008
38
1.061 1.120 2,888
39
1.030 1.085 2,773
40
0.999 1.051 2,663
41
0.969 1.019 2,559
42
0.940 0.987 2,459
43
0.912 0.956 2,363
44
0.885 0.926 2,272
45
0.858 0.896 2,184
46
0.832 0.868 2,101
47
0.807 0.841 2,021
48
0.782 0.814 1,944
49
0.758 0.788 1,871
50
0.735 0.763 1,801
51
0.713 0.739 1,734
52
0.691 0.716 1,670
53
0.669 0.693 1,609
54
0.649 0.671 1,550
55
0.629 0.650 1,493
56
0.610 0.629 1,439
57
0.591 0.609 1,387
58
0.573 0.590 1,337
59
0.555 0.571 1,290
60
0.538 0.553 1,244
61
0.522 0.536 1,200
TEMP
(C)
VOLTAGE
DROP A
(V)
VOLTAGE
DROP B
(V)
RESISTANCE
(Ohms)
62
0.506 0.519 1,158
63
0.490 0.502 1,118
64
0.475 0.487 1,079
65
0.461 0.471 1,041
66
0.447 0.457 1,006
67
0.433 0.443 971
68
0.420 0.429 938
69
0.407 0.415 906
70
0.395 0.403 876
71
0.383 0.390 836
72
0.371 0.378 805
73
0.360 0.367 775
74
0.349 0.355 747
75
0.339 0.345 719
76
0.329 0.334 693
77
0.319 0.324 669
78
0.309 0.314 645
79
0.300 0.305 623
80
0.291 0.295 602
81
0.283 0.287 583
82
0.274 0.278 564
83
0.266 0.270 547
84
0.258 0.262 531
85
0.251 0.254 516
86
0.244 0.247 502
87
0.237 0.239 489
88
0.230 0.232 477
89
0.223 0.226 466
90
0.217 0.219 456
91
0.211 0.213 446
92
0.204 0.207 436
93
0.199 0.201 427
94
0.193 0.195 419
95
0.188 0.189 410
96
0.182 0.184 402
97
0.177 0.179 393
98
0.172 0.174 385
99
0.168 0.169 376
100
0.163 0.164 367
101
0.158 0.160 357
102
0.154 0.155 346
103
0.150 0.151 335
104
0.146 0.147 324
105
0.142 0.143 312
106
0.138 0.139 299
107
0.134 0.135 285
