KP915GV Product Manual
32
• All configuration is automatic - no stopping on configuration change
• Resources freed when unused
2.19 Operating Systems Support
• Windows XP Professional SP2
• Embedded Windows XP Server SP2
• Red Hat Enterprise Linux 4.0 AS
• Knoppix Linux 3.7 (selected drivers only)
• Windows 2000 Server SP4
• SUSE Linux Enterprise Server 9.0 (selected drivers only)
2.20 Power Supplies
• Support for ATX12V power supplies (see Note below)
• Supports hard- and soft-switched power supplies with jumper-less configuration
• See table 4 for required power supply connector.
Table 4. Power Supply Connector
Board Connector Type
KP915GV 2 x 10 pin
It is recommended that the board be used with a power supply that supports a
minimum current load of 0.3A or less on the 5V supply rail and 2A or less on the
3.3V supply rail (see note below).
Note: This board with CPU and memory may draw as little as 400mA of 5V and 2A
of 3.3V during start-up (increases depend on installed devices). The power supply
under consideration must be verified as compatible with the projected total system
start-up loads for these supply rails. If the power supply minimum current level
requirements are not at or below the level of current loads that are actually drawn,
unpredictable start-up operation may result, such as the power supply latching off.
If this occurs, the AC input to the power supply must be removed and re-attached
or the power supply switch cycled off and on, in order to turn the system back on.
