81
Enhancements
Release K.13.04 Enhancements
Displaying the VRRP Configuration
You can display the VRRP tracked entities by entering the command shown in Figure 11.
Figure 11. Example of show vrrp tracked entities Command
You can display the VRRP configuration by entering the command shown in Figure 12.
Figure 12. Example Showing the VRRP Configuration
Operating Notes
• There are no backward compatibility issues with this enhancement. If a VRRP router
has an older firmware version that does not have the dynamic priority changeover
feature, it will not have the needed configuration options.
ProCurve(vlan-25-vrid-1)# show vrrp tracked-entities
VRRP Tracked entities
VLAN ID VR ID Type ID
---------- ---------- ---------- ------------------------------
25 1 port 7
25 1 port 12
25 1 port 13
25 1 port 14
25 1 vlan 1
ProCurve(vlan-25-vrid-1)# show vrrp vlan 25 vrid 1 config
VRRP Virtual Router Configuration Information
Vlan ID : 25
Virtual Router ID : 1
Administrative Status [Disabled] : Enabled
Mode [Uninitialized] : Owner
Priority [100] : 255
Advertisement Interval [1] : 1
Preempt Mode [True] : True
Preempt Delay Time [0] : 0
Primary IP Address : Lowest
IP Address Subnet Mask
--------------- ---------------
10.10.10.1 255.255.255.0
