Chapter 7 Wireless LAN
P-2812HNU-51c User’s Guide
164
Click Network > Wireless LAN >WPS. The following screen displays.
Figure 69 Network > Wireless LAN > WPS
The following table describes the labels in this screen.
Table 42 Network > Wireless LAN > WPS
LABEL DESCRIPTION
WPS Setup
Enable WPS Select the check box to activate WPS on the P-2812HNU-51c.
PIN Number This shows the PIN (Personal Identification Number) of the P-2812HNU-
51c. Enter this PIN in the configuration utility of the device you want to
connect to using WPS.
The PIN is not necessary when you use WPS push-button method.
Generate Click this button to have the P-2812HNU-51c create a new PIN.
WPS Status This displays Configured when the P-2812HNU-51c has connected to a
wireless network using WPS or Enable WPS is selected and wireless or
wireless security settings have been changed. The current wireless and
wireless security settings also appear in the screen.
This displays Unconfigured if WPS is disabled and there is no wireless
or wireless security changes on the P-2812HNU-51c or you click
Release_Configuration to remove the configured wireless and
wireless security settings.
Release_Co
nfiguration
This button is available when the WPS status is Configured but not
configurable if you disable WPS.
Click this button to remove all configured wireless and wireless security
settings for WPS connections on the P-2812HNU-51c.
Apply Click Apply to save your changes back to the P-2812HNU-51c.
