Chapter 3 Introducing the Web Configurator
P-2812HNU-51c User’s Guide
76
Trigger Port Use this screen to change your P-2812HNU-51c’s port triggering
settings.
DMZ Host Use this screen to configure a default server which receives
packets from ports that are not specified in the Port Forwarding
screen.
ALG Use this screen to allow SIP sessions to pass through the P-
2812HNU-51c.
VoIP
SIP SIP Account Use this screen to configure your P-2812HNU-51c’s Voice over IP
settings. Use this screen to set which phone ports use which SIP
accounts.
SIP Service
Provider
Use this screen to configure the SIP server information, QoS for
VoIP calls, the numbers for certain phone functions and dialing
plan
Phone Region Use this screen to select your location and call service mode.
Phone Book Speed Dial Use this screen to configure speed dial for SIP phone numbers
that you call often.
Call History Call History
Summary
Use this screen to view the summary list of received, dialed and
missed calls.
Outgoing Calls Use this screen to view detailed information for each outgoing call
you made
Incoming Calls Use this screen to view detailed information for each incoming call
from someone calling you.
USB Services
File Sharing Share
Configuration
Use this screen to enable file sharing via the P-2812HNU-51c.
Print Server Printer
Configuration
Use this screen to enable the print server on the P-2812HNU-51c
and get the model name of the associated printer.
Security
IPSec IPSec Use this screen to view the configured VPN policies and add, edit
or remove a VPN policy.
Status Use this screen to view and manage the current active VPN
connections.
Firewall Incoming This screen shows a summary of the IP filtering rules, and allows
you to add or remove an incoming IP filtering rule that allows
incoming traffic from the WAN.
Certificates Local
Certificates
Use this screen to view a summary list of certificates and manage
certificates and certification requests.
Trusted CA Use this screen to view and manage the list of the trusted CAs.
Advanced
Static Route IP Static Route Use this screen to configure IP static routes to tell your device
about networks beyond the directly connected remote nodes.
Policy
Forwarding
Use this screen to configure policy routing on the P-2812HNU-
51c.
DNS Route Use this screen to view and configure DNS routes.
Table 6 Navigation Panel Summary
LINK TAB FUNCTION
