Chapter 19 Quality of Service (QoS)
P-2812HNU-51c User’s Guide
322
Non-
Conforming
Action
Specify the action that the P-2812HNU-51c takes on red-marked packets.
Select Drop to discard the packets.
Select DSCP Mark to assign a specified DSCP number (between 0 and 63)
to the packets and forward them. The packets are dropped if there is
congestion on the network.
Regulated
Classes
Member
Setting
Available
Class
Selected
Class
Select a QoS classifier to apply this QoS policer to traffic that matches the
QoS classifier.
Highlight a QoS classifier in the Available Class box and use the Add >>
button to move it to the Selected Class box.
To remove a QoS classifier from the Selected Class box, select it and use
the Remove button.
Back Click Back to return to the previous screen without saving.
Apply Click Apply to save your changes back to the P-2812HNU-51c.
Cancel Click Cancel to begin configuring this screen afresh.
Table 107 QoS Policer Setup: Add
LABEL DESCRIPTION
