Paper-path test (and automatic sensors test)
Paper-path test
1. Press the Menu button
.
2. Press the down arrow
button or the up arrow button to navigate to the DIAGNOSTICS menu,
and then press the OK button.
3. Press the down arrow
button or the up arrow button to navigate to the PAPER PATH TEST
sub menu, and then press the OK button.
4. Select the paper path test options for the test you want to run
NOTE: Values that have an asterisk (*) are the factory-default values. Some menu items have no
default.
Item Sub-item Values Description
PAPER PATH TEST Tests the paper-handling features
of the product, such as the
configuration of the trays.
PRINT TEST PAGE Generates a page for testing the
paper-handling features. You must
define the path for the test to test
specific paper paths.
SOURCE ALL TRAYS
TRAY 1
TRAY 2*
TRAY 3
TRAY 4
Specifies whether the test page is
printed from all trays or from a
specific tray.
DUPLEX OFF
ON
Determines whether the duplexer
is used in the test.
COPIES 1*
10
50
100
500
Determines how many pages to
send from the specified source as
part of the test.
Paper-path sensors test
1. Press the Menu button
.
2. Press the down arrow
button or the up arrow button to navigate to the DIAGNOSTICS menu,
and then press the OK button.
3. Press the down arrow
button or the up arrow button to navigate to the PAPER PATH
SENSORS sub menu, and then press the OK button.
