Numerical parts list
Table 4-17 Numerical parts list
Part number Description Table and page
CE530-69001 Optional 500-sheet tray and feeder unit 500-sheet input tray (Tray 3
and Tray 4) on page 289
RC2-7670-000CN Cover, right Covers on page 275
RC2-7672-000CN Cover, right-front Covers on page 275
RC2-7673-000CN Cover, right-rear Covers on page 275
RC2-7674-000CN Cover, DIMM Covers on page 275
RC2-7675-000CN Cover, handle right Covers on page 275
RC2-7676-000CN Cover, upper-right (top-right); duplex models Covers on page 275
RC2-7677-000CN Cover, upper-right (top-right) sub; duplex models Covers on page 275
RC2-7688-000CN Cover, formatter Covers on page 275
RC2-7707-000CN Cover, upper-right (top-right); simplex models Covers on page 275
RC2-7933-000CN Stopper, bushing arm Internal assemblies (1 of 6)
on page 277
RC2-8575-000CN Pad, multipurpose separation Internal assemblies (3 of 6)
on page 281
RK2-1490-000CN Tray 1 solenoid Internal assemblies (2 of 6)
on page 279
RK2-1492-000CN Tray 2 solenoid Internal assemblies (2 of 6)
on page 279
RK2-1497-000CN Fan, main Internal assemblies (5 of 6)
on page 285
RK2-1499-000CN Fan, sub Internal assemblies (4 of 6)
on page 283
RK2-2788-000CN Cable, flat Internal assemblies (5 of 6)
on page 285
RK2-3101-000CN Cable, flat Internal assemblies (4 of 6)
on page 283
RK2-3103-000CN Cable, flat Internal assemblies (1 of 6)
on page 277
RL1-2412-000CN Roller, multipurpose Internal assemblies (3 of 6)
on page 281
RM1-6263-000CN Lower paper feed guide; duplex models Internal assemblies (4 of 6)
on page 283
RM1-6264-000CN Cartridge-door assembly Covers on page 275
RM1-6265-000CN Cover, multipurpose assembly Covers on page 275
RM1-6266-000CN Multipurpose lifting plate assembly Covers on page 275
RM1-6268-000CN Cassette, paper pickup assembly; duplex models Internal assemblies (5 of 6)
on page 285
ENWW Numerical parts list 293
