Assembly locations
Base product (no optional trays or accessories)
Figure 4-1 Base product (no optional trays or accessories)
Table 4-6 Base product
Item Description Item Description
1 Control panel 7 Power recepticle
2 DIMM cover 8 Tray 2 cassette
3 Front-right and right-side
cover assembly
9 Tray 1 (multipurpose tray)
4 Power switch 10 Cartridge-door assembly
(print-cartridge door)
5 Left cover 11 Output bin (face-down tray)
6 Rear-door assembly
