Item Sub-item Values Description
SOURCE ALL TRAYS
TRAY 1
TRAY 2*
TRAY 3
TRAY 4
Specifies whether the test page is
printed from all trays or from a
specific tray.
DUPLEX OFF
ON
Determines whether the duplexer
is used in the test.
COPIES 1*
10
50
100
500
Determines how many pages
should be sent from the specified
source as part of the test.
MANUAL SENSOR TEST Performs tests to determine
whether the paper-path sensors
are operating correctly.
MANUAL SENSOR
TEST 2
Performs additional tests to
determine whether the paper-path
sensors are operating correctly.
COMPONENT TEST A list of available components
appears.
Activate individual parts
independently to isolate noise and
other hardware issues.
PRINT/STOP TEST Range is 0 - 60,000 milliseconds.
The default is 0.
Isolates print quality faults more
accurately by stopping the product
in midprint cycle, which allows you
to see where the image begins to
degrade. This causes a jam
message that might need to be
manually cleared. A service
representative should perform this
test.
PRINT FUSER TEST
PAGE
Tests the fuser for offset problems
or contamination.
