Alphabetical parts list
Table 4-16 Alphabetical parts list
Description Part number Table and page
Base plate roller assembly RM1-6306-000CN Internal assemblies (3 of 6)
on page 281
Base plate roller assembly RM1-6306-000CN 500-sheet input tray (Tray 3
and Tray 4) on page 289
Cable, flat RK2-3103-000CN Internal assemblies (1 of 6)
on page 277
Cable, flat RK2-3101-000CN Internal assemblies (4 of 6)
on page 283
Cable, flat RK2-2788-000CN Internal assemblies (5 of 6)
on page 285
Cartridge-door assembly RM1-6264-000CN Covers on page 275
Cassette RM1-6279-000CN Internal assemblies (3 of 6)
on page 281
Cassette RM1-6279-000CN 500-sheet input tray (Tray 3
and Tray 4) on page 289
Cassette pickup roller RM1-6313-000CN Internal assemblies (5 of 6)
on page 285
Cassette, paper pickup assembly; duplex models RM1-6268-000CN Internal assemblies (5 of 6)
on page 285
Cassette, paper pickup assembly; simplex models RM1-6299-000CN Internal assemblies (5 of 6)
on page 285
Control panel; duplex models RM1-6518-000CN Covers on page 275
Control panel; duplex models RM1-6519-000CN Covers on page 275
Cover, DIMM RC2-7674-000CN Covers on page 275
Cover, formatter RC2-7688-000CN Covers on page 275
Cover, handle right RC2-7675-000CN Covers on page 275
Cover, left RM1-6291-000CN Covers on page 275
Cover, multipurpose assembly RM1-6265-000CN Covers on page 275
Cover, rear assembly RM1-6292-000CN Covers on page 275
Cover, right RC2-7670-000CN Covers on page 275
Cover, right-front RC2-7672-000CN Covers on page 275
Cover, right-rear RC2-7673-000CN Covers on page 275
Cover, top assembly RM1-6289-000CN Covers on page 275
Cover, upper-right (top-right) sub; duplex models RC2-7677-000CN Covers on page 275
Cover, upper-right (top-right); duplex models RC2-7676-000CN Covers on page 275
Cover, upper-right (top-right); simplex models RC2-7707-000CN Covers on page 275
