Description Part number Table and page
Paper-feed guide assembly RM1-6270-000CN Internal assemblies (4 of 6)
on page 283
Photo interrupter, TLP1243 WG8-5696-000CN Internal assemblies (1 of 6)
on page 277
Photo interrupter, TLP1243 WG8-5696-000CN Internal assemblies (6 of 6)
on page 287
Pickup roller set, cassette RM1-6313-000CN 500-sheet input tray (Tray 3
and Tray 4) on page 289
Position-guide assembly; duplex models RM1-6273-000CN Internal assemblies (4 of 6)
on page 283
Registration roller assembly RM1-6272-000CN Internal assemblies (3 of 6)
on page 281
Roller, multipurpose RL1-2412-000CN Internal assemblies (3 of 6)
on page 281
Roller, transfer RM1-6321-000CN Internal assemblies (3 of 6)
on page 281
Separation holder assembly RM1-6303-000CN Internal assemblies (3 of 6)
on page 281
Separation holder assembly RM1-6303-000CN 500-sheet input tray (Tray 3
and Tray 4) on page 289
Stopper, bushing arm RC2-7933-000CN Internal assemblies (1 of 6)
on page 277
Switch assembly, power RM1-6283-000CN Internal assemblies (4 of 6)
on page 283
Tag holder assembly RM1-6284-000CN Internal assemblies (1 of 6)
on page 277
TOP sensor PCA RM1-6511-000CN Internal assemblies (4 of 6)
on page 283
Transfer lower guide assembly RM1-6315-000CN Internal assemblies (3 of 6)
on page 281
Tray sensor PCA RM1-6487-000CN Internal assemblies (6 of 6)
on page 287
Tray 1 solenoid RK2-1490-000CN Internal assemblies (2 of 6)
on page 279
Tray 2 solenoid RK2-1492-000CN Internal assemblies (2 of 6)
on page 279
Table 4-16 Alphabetical parts list (continued)
