Part number Description Table and page
RM1-6270-000CN Paper-feed guide assembly Internal assemblies (4 of 6)
on page 283
RM1-6271-000CN Idler roller assembly Internal assemblies (5 of 6)
on page 285
RM1-6272-000CN Registration roller assembly Internal assemblies (3 of 6)
on page 281
RM1-6273-000CN Position-guide assembly; duplex models Internal assemblies (4 of 6)
on page 283
RM1-6274-000CN Fuser assembly 110V Internal assemblies (5 of 6)
on page 285
RM1-6279-000CN Cassette Internal assemblies (3 of 6)
on page 281
RM1-6279-000CN Cassette 500-sheet input tray (Tray 3
and Tray 4) on page 289
RM1-6280-000CN High-voltage power supply; duplex models Internal assemblies (4 of 6)
on page 283
RM1-6281-000CN Engine controller PCA 110V Internal assemblies (5 of 6)
on page 285
RM1-6283-000CN Switch assembly, power Internal assemblies (4 of 6)
on page 283
RM1-6284-000CN Tag holder assembly Internal assemblies (1 of 6)
on page 277
RM1-6289-000CN Cover, top assembly Covers on page 275
RM1-6291-000CN Cover, left Covers on page 275
RM1-6292-000CN Cover, rear assembly Covers on page 275
RM1-6296-000CN Fuser motor assembly Internal assemblies (6 of 6)
on page 287
RM1-6299-000CN Cassette, paper pickup assembly; simplex models Internal assemblies (5 of 6)
on page 285
RM1-6300-000CN High-voltage power supply; simplex models Internal assemblies (4 of 6)
on page 283
RM1-6301-000CN Paper delivery roller assembly Internal assemblies (6 of 6)
on page 287
RM1-6303-000CN Separation holder assembly Internal assemblies (3 of 6)
on page 281
RM1-6303-000CN Separation holder assembly 500-sheet input tray (Tray 3
and Tray 4) on page 289
RM1-6306-000CN Base plate roller assembly Internal assemblies (3 of 6)
on page 281
RM1-6306-000CN Base plate roller assembly 500-sheet input tray (Tray 3
and Tray 4) on page 289
RM1-6311-000CN Face-down roller assembly Internal assemblies (6 of 6)
on page 287
Table 4-17 Numerical parts list (continued)
294 Chapter 4 Parts and diagrams ENWW
