Table 4-13 Internal assemblies (5 of 6)
Ref Description Part number Qty
1 Fan, main RK2-1497-000CN 1
2 Cassette, paper pickup assembly; duplex models RM1-6268-000CN 1
2 Cassette, paper pickup assembly; simplex models RM1-6299-000CN 1
3 Idler roller assembly RM1-6271-000CN 1
4 Multipurpose sensor PCA RM1-6510-000CN 1
5 Fuser assembly 110V RM1-6274-000CN 1
5 Fuser assembly 220V RM1-6319-000CN 1
6 Engine controller PCA 110V RM1-6281-000CN 1
6 Engine controller PCA 220V RM1-6318-000CN 1
7 Front USB PCA RM1-6514-000CN 1
8 Microswitch WC4-5171-000CN 1
9 Environmental sensor assembly RM1-6515-000CN 2
10 Cassette pickup roller RM1-6313-000CN 1
11 Cable, flat RK2-2788-000CN 1
