Physical specifications
Table B-1 Product dimensions and weights
Product model Height Depth Width Weight
Base, d, n, and dn models 316 mm (12.4 in) 412 mm (16.2 in) 448 mm (17.6 in) 15.9 kg (35.1 lb)
x model 456 mm (17.9 in) 412 mm (16.2 in) 448 mm (17.6 in) 21.2 kg (46.8 lb)
Optional 500-sheet feeder 140 mm (5.5 in) 412 mm (16.2 in) 448 mm (17.6 in) 5.3 kg (11.7 lb)
Table B-2 Product dimensions with all doors and trays fully opened
Product model Height Depth Width
Base, d, n, and dn models 347 mm (13.7 in) 1040 mm (41.0 in) 448 mm (17.6 in)
x model 487 mm (19.2 in) 1040 mm (41.0 in) 448 mm (17.6 in)
Electrical specifications
WARNING! Power requirements are based on the country/region where the product is sold. Do not
convert operating voltages. This can damage the product and void the product warranty.
Table B-3 Power requirements
Specification 110-volt models 220-volt models
Power requirements 100 to 127 Vac
50/60 Hz
220 to 240 Vac
50/60 Hz
Rated current 8.6 Amps 4.2 Amps
Table B-4 Power consumption (average, in watts)
1
Model Printing
2
Ready or
standby
,
4
Sleep
3
Off
HP LaserJet P3015 780 W 14.5 W 8.5 W 0.6 W
1
Values are based on preliminary data. See www.hp.com/go/ljp3010series_regulatory for current information.
2
Power numbers are the highest values measured using all standard voltages.
3
Default time from Ready mode to Sleep = 30 minutes.
4
Heat dissipation in Ready mode = 50 BTU/hour.
Acoustic specifications
Table B-5 Sound power and pressure level
Product model Sound power level
1
,
2
Declared per ISO 9296
HP LaserJet P3015 models Printing L
WAd
= 6.8 Bels (A) [68 dB(A)]
Ready Inaudible
308 Appendix B Specifications ENWW
